ASME B16.5-2020 Pipe Flanges and Flanged Fittings: NPS 1/2 Through NPS 24

ASME B16.5-2020 Pipe Flanges and Flanged Fittings: NPS 1/2 Through NPS 24 by ASME (2020) — available for instant access at Publications Office.

ASME B16.5 American Society of Mechanical Engineers (ASME) 2020

PDF download

$69.99

Searchable PDF · printing enabled · download after successful payment

Buy PDF — $69.99

About this publication

ASME B16.5 Pipe Flanges and Flanged Fittings: NPS 1/2 through NPS 24 Metric/Inch Standard covers pressure-temperature ratings, materials, dimensions, tolerances, marking, testing, and methods of designating openings for pipe flanges and flanged fittings. Included are: (1) flanges with rating class designations 150, 300, 400, 600, 900, and 1500 in sizes NPS 1/2 through NPS 24 and flanges with rating class designation 2500 in sizes NPS 1/2 through NPS 12, with requirements given in both metric and U.S. Customary units with diameter of bolts and flange bolt holes expressed in inch units; (2) flanged fittings with rating class designation 150 and 300 in sizes NPS 1/2 through NPS 24, with requirements given in both metric and U.S. Customary units with diameter of bolts and flange bolt holes expressed in inch units; (3) flanged fittings with rating class designation 400, 600, 900, and 1500 in sizes NPS 1/2 through NPS 24 and flanged fittings with rating class designation 2500 in sizes NPS 1/2 through NPS 12 that are acknowledged in Non-Mandatory Appendix E in which only U.S. Customary units are provided.
